PVC Cleats | |||||
Appearance | Type | Hardness (ShoreA) | Specification B*H (mm) | Color | Min. diameter (mm) |
T20 | 60 | 20*20 | Green White Transparent | 90 | |
T30 | 25*30 | 120 | |||
T40 | 25*40 | 120 | |||
T50 | 25*50 | 120 | |||
T60 | 40*60 | 150 | |||
T75 | 45*75 | 160 | |||
T80 | 47*80 | 180 | |||
X30 | 60 | 25*30 | Green White Transparent | 40 | |
X40 | 30*40 | 60 | |||
X50 | 30*50 | 80 | |||
X60 | 35*60 | 80 | |||
X70 | 40*70 | 100 | |||
X80 | 43*80 | 120 |
PU Cleats | |||||
Appearance | Type | Hardness (ShoreA) | Specification B*H (mm) | Color | Min. diamete r (mm) |
UT20 | 86 | 10*20 | Green White Transparent | 35 | |
UT30 | 15*30 | 40 | |||
UT40 | 15*40 | 40 |
