Boshun Belting is known for light duty conveyor belt for logistics & airport industries. Our belts has characteristics of light weight, good elasticity, small elongation, long service life and etc. Wherein, the planar and skid resistant belts are anti-static, corrosion-cut resistant, flame resistant, and low noise. It can keep stable under the high speed movementand friction. Currently PVK conveyor belt is widely used in logistics.
| Type | Thickness (mm) |
Ply | Effective pull at 1% elongation (N/mm) |
Min diameter (mm) |
Temperature range (℃) |
|
| 20P21-34/0 | 2.0 | 2 | 10 | 30 | -15/80 | 20P21-34/0 2 Black Matt 2.0mm 0.5mm 2.2Kg/㎡ 10N/mm 30mm -15/80℃ https://boshunbelting.com #000000 |
| 20P25-14/1A | 2.0 | 2 | 8 | 30 | -15/80 | 20P25-14/1A 2 Green Diamond 2.0mm 1.0mm 2.3Kg/㎡ 8N/mm 30mm -15/80℃ https://boshunbelting.com #00b050 |
| 20P25-44/1BZA | 2.0 | 2 | 6 | 40 | -15/80 | 20P25-44/1BZA 2 Grey Diamond 2.0mm 0.5mm 2.3Kg/㎡ 6N/mm 40mm -15/80℃ https://boshunbelting.com #7f7f7f |
| 30P22-16/19A | 3.0 | 2 | 10 | 60 | -20/60 | 30P22-16/19A 2 Green Longitudinal rib 3.0mm 1.5mm 3.4Kg/㎡ 10N/mm 60mm -20/60℃ https://boshunbelting.com #00b050 |
| 30P25-15A | 3.0 | 2 | 8 | 50 | -15/80 | 30P25-15A 2 Green Smooth 3.0mm 1.2mm 3.6Kg/㎡ 8N/mm 50mm -15/80℃ https://boshunbelting.com #00b050 |
| 30P25-35/0A | 3.0 | 2 | 8 | 50 | -15/80 | 30P25-35/0A 2 Black Matt 3.0mm 1.2mm 3.6Kg/㎡ 8N/mm 50mm -15/80℃ https://boshunbelting.com #000000 |
| 31P22-36/19D | 3.1 | 2 | 12 | 60 | -20/60 | 31P22-36/19D 2 Black Longitudinal rib 3.1mm 1.4mm 3.1Kg/㎡ 12N/mm 60mm -20/60℃ https://boshunbelting.com #000000 |
| 40P32-14A | 4.0 | 3 | 15 | 80 | -15/80 | 40P32-14A 3 Green Smooth 4.0mm 1.0mm 4.8Kg/㎡ 15N/mm 80mm -15/80℃ https://boshunbelting.com #00b050 |
| 40P32-74/0D | 4.0 | 3 | 12 | 80 | -15/80 | 40P32-74/0D 3 Black Matt 4.0mm 1.0mm 4.8Kg/㎡ 12N/mm 80mm -15/80℃ https://boshunbelting.com #000000 |
| 50P22-16/3A | 5.0 | 2 | 10 | 80 | -20/70 | 50P22-16/3A 2 Green Rough top 5.0mm 3.5mm 4.7Kg/㎡ 10N/mm 80mm -20/70℃ https://boshunbelting.com/public/uploads/20190316/7869d4601b5b0f6f8941e785a20e1848.jpg #00b050 |
| 50P22-16/9A | 5.0 | 2 | 10 | 60 | -20/60 | 50P22-16/9A 2 Green Wavy super grip 5.0mm 3.0mm 4.2Kg/㎡ 10N/mm 60mm -20/60℃ https://boshunbelting.com #00b050 |
| 53P22-36/9D | 5.3 | 2 | 10 | 50 | -20/60 | 53P22-36/9D 2 Black Wavy super grip 5.3mm 3.5mm 4.4Kg/㎡ 10N/mm 50mm -20/60℃ https://boshunbelting.com #000000 |
| 40P33-27G | 4.0 | 3 | 10 | 140 | -15/80 | 40P33-27G 3 White Fabric 4.0mm 1.0mm 4.8Kg/㎡ 10N/mm 140mm -15/80℃ https://boshunbelting.com/public/uploads/20181214/6d9e8120e669b21631781f5ab9099f55.jpg #ffffff Automotive & Tyre |
| 30PVK100 | 3.0 | 1 | 15 | 60 | -15/95 | 30PVK100 1 Black Fabric 3.0mm 0.2/0.1mm 3.4Kg/㎡ 15N/mm 60mm -15/95℃ https://boshunbelting.com #000000 |
| 38PVK125 | 3.8 | 1 | 20 | 80 | -15/95 | 38PVK125 1 Black Fabric 3.8mm 0.2/0.1mm 4.0Kg/㎡ 20N/mm 80mm -15/95℃ https://boshunbelting.com #000000 |
| 40PVK130 | 4.0 | 1 | 22 | 90 | -15/95 | 40PVK130 1 Black Fabric 4.0mm 0.2/0.1mm 4.2Kg/㎡ 22N/mm 90mm -15/95℃ https://boshunbelting.com #000000 |
| 43PVK150 | 4.3 | 1 | 25 | 100 | -15/95 | 43PVK150 1 Black Fabric 4.3mm 0.2/0.1mm 4.5Kg/㎡ 25N/mm 100mm -15/95℃ https://boshunbelting.com #000000 |
